ETC - Source Four Zoom 25-50° (Cutting)

The ETC S4 halogen Zoom cutout is used in theater, events, and TV.
It is equipped with a specific HPL type lamp for a high luminous flux..
Simplified focus adjustment with a single dial.
Possibility of installing a gobo holder for projection of company logos or other.

TECHNICAL CHARACTERISTICS
- Manufactured from extruded aluminum
- One-handed zoom focus with locking mechanism
- Lens door for easy cleaning of the lens
- Double grip yoke locking mechanism
- Graduated marks for adjusting the angle of view and focus
- Thermally insulated rear handle and buttons
- Incorporated die-cast filter holder/accessories, with top gelatin attachment
- Steel lyre with 2 mounting positions
- Housing for glass or metal gobos
- Anti-reflective coated lenses
- Faceted reflectors with dichroic coating
- 95% of visible light is reflected through the optical assembly
- 90% of infrared radiation (heat) passes through the reflector
- Lenses and reflectors fixed by anti-vibration dampers
- Lamps: 750 W HPL
- Model 25° - 50°: 584 x 340 x 365 mm
- Weight: 8.5 kg

Dimensions :

Weight:	21.00 kg
Categories:	Technical Lighting & effects Projectors
